SEL-787 Settings Sheets
Global Settings (SET G Command)
SEL-787 Relay Instruction Manual Date Code 20081022
Date _______________
Group______________
AIx02 HI WARN L2 (OFF, –99999.000 to +99999.000) AIx02HW2 :=
AI
x02 HI ALARM (OFF, –99999.000 to +99999.000) AIx02HAL :=
AIx03
AIx03 TAG NAME (8 characters 0–9, A–Z, _) AIx03NAM :=
AI
x03 TYPE (I, V) AIx03TYP :=
If AI
x03TYP = I
AI
x03 LOW IN VAL (–20.480 to +20.480; mA) AIx03L :=
AI
x03 HI IN VAL (–20.480 to +20.480; mA) AIx03H :=
If AI
x03TYP = V
AI
x03 LOW IN VAL (–10.240 to +10.240 V) AIx03L :=
AI
x03 HI IN VAL (–10.240 to +10.240 V) AIx03H :=
AI
x03 ENG UNITS (16 characters) AIx03EU :=
AI
x03 EU LOW (–99999.000 to +99999.000) AIx03EL :=
AI
x03 EU HI (–99999.000 to +99999.000) AIx03EH :=
AI
x03 LO WARN L1 (OFF, –99999.000 to +99999.000) AIx03LW1 :=
AI
x03 LO WARN L2 (OFF, –99999.000 to +99999.000) AIx03LW2 :=
AI
x03 LO ALARM (OFF, –99999.000 to +99999.000) AIx03LAL :=
AI
x03 HI WARN L1 (OFF, –99999.000 to +99999.000) AIx03HW1 :=
AI
x03 HI WARN L2 (OFF, –99999.000 to +99999.000) AIx03HW2 :=
AI
x03 HI ALARM (OFF, –99999.000 to +99999.000) AIx03HAL :=
AIx04
AIx04 TAG NAME (8 characters 0–9, A–Z, _) AIx04NAM :=
AI
x04 TYPE (I, V) AIx04TYP :=
If AI
x04TYP = I
AI
x04 LOW IN VAL (–20.480 to +20.480; mA) AIx04L :=
AI
x04 HI IN VAL (–20.480 to +20.480; mA) AIx04H :=
If AI
x04TYP = V
AI
x04 LOW IN VAL (–10.240 to +10.240 V) AIx04L :=
AI
x04 HI IN VAL (–10.240 to +10.240 V) AIx04H :=
AI
x04 ENG UNITS (16 characters) AIx04EU :=
AI
x04 EU LOW (–99999.000 to +99999.000) AIx04EL :=
AI
x04 EU HI (–99999.000 to +99999.000) AIx04EH :=
AI
x04 LO WARN L1 (OFF, –99999.000 to +99999.000) AIx04LW1 :=
AI
x04 LO WARN L2 (OFF, –99999.000 to +99999.000) AIx04LW2 :=
AI
x04 LO ALARM (OFF, –99999.000 to +99999.000) AIx04LAL :=
AI
x04 HI WARN L1 (OFF, –99999.000 to +99999.000) AIx04HW1 :=
AI
x04 HI WARN L2 (OFF, –99999.000 to +99999.000) AIx04HW2 :=
AI
x04 HI ALARM (OFF, –99999.000 to +99999.000) AIx04HAL :=
