SEL-787 Settings Sheets
Global Settings (SET G Command)
Analog Outputs
For the following settings, x is the card position (3, 4, or 5 in Slot C, D, and E, respectively).
AOx01
AOx01 ANALOG QTY (Off, 1 analog quantity) AOx01AQ :=
AO
x01 TYPE (I, V) AOx01TYP :=
AO
x01 AQTY LOW (–2147483647 to +2147483647) AOx01AQL :=
AO
x01 AQTY HI (–2147483647 to +2147483647) AOx01AQH :=
If AO
x01TYP = I
AO
x01 LO OUT VAL (–20.480 to +20.480 mA) AOx01L :=
AO
x01 HI OUT VAL (–20.480 to +20.480 mA) AOx01H :=
If AO
x01TYP = V
AO
x01 LO OUT VAL (–10.240 to +10.240 V) AOx01L :=
AO
x01 HI OUT VAL (–10.240 to +10.240 V) AOx01H :=
AOx02
AOx02 ANALOG QTY (Off, 1 analog quantity) AOx02AQ :=
AO
x02 TYPE (I, V) AOx02TYP :=
AO
x02 AQTY LOW (–2147483647 to +2147483647) AOx02AQL :=
AO
x02 AQTY HI (–2147483647 to +2147483647) AOx02AQH :=
If AO
x02TYP = I
AO
x02 LO OUT VAL (–20.480 to +20.480 mA) AOx02L :=
AO
x02 HI OUT VAL (–20.480 to +20.480 mA) AOx02H :=
If AO
x02TYP = V
AO
x02 LO OUT VAL (–10.240 to +10.240 V) AOx02L :=
AO
x02 HI OUT VAL (–10.240 to +10.240 V) AOx02H :=
AOx03
AOx03 ANALOG QTY (Off, 1 analog quantity) AOx03AQ :=
AO
x03 TYPE (I, V) AOx03TYP :=
AO
x03 AQTY LOW (–2147483647 to +2147483647) AOx03AQL :=
AO
x03 AQTY HI (–2147483647 to +2147483647) AOx03AQH :=
If AO
x03TYP = I
AO
x03 LO OUT VAL (–20.480 to +20.480 mA) AOx03L :=
AO
x03 HI OUT VAL (–20.480 to +20.480 mA) AOx03H :=
If AO
x03TYP = V
AO
x03 LO OUT VAL (–10.240 to +10.240 V) AOx03L :=
AO
x03 HI OUT VAL (–10.240 to +10.240 V) AOx03H :=
