Section06ELECTRICALSYSTEM
Subsection 04 (INSTRUMENTS AND ACCESSORIES)
FUEL LEVEL INDICATOR
Bar gauge continuously indicates the amount of
fuel in the fuel tank while riding. A low-fuel con-
dition is also indicated in the information center
when only one bar is displayed. See UNITS AND
MESSAGES SECTION below.
NUMERICAL SECTION
This section shows the digits of the function dis-
played such as:
Digital Tachometer: Indicates the revolution per
minute (RPM) of the engine.
Digital Speedometer: Indicates the speed of the
watercraft in miles per hour (MPH) and kilometers
per hour (km/h).
Depth Gauge (GTX 4-TEC Limited models): It
continuously display the water depth under the
hull within 0 to 50 meters (0 to 170 feet).
WARNING
Never use the depth gauge as a warning de-
vice to ride in shallow water. Use it as a navi-
gation guide only. Not to be used for naviga-
tion purposes.
Compass (all models except RXP and RXT): Dis-
plays the cardinal points to indicate the orientation
of the watercraft.
WARNING
Use the compass as a guide only. Not to be
used for navigation purposes.
Average Speed: The information center approxi-
mately calculates and displays the average speed
(AV KM/H or AV MPH) of the watercraft since the
last engine start.
Distance (KM or MILES): The information cen-
ter approximately calculates the distance based
on the operation time and the watercraft speed
and displays the result in kilometers (KM) or miles
(MILES).
Hour Meter: Displays the time in hours of the
watercraft usage (HOUR).
Water Temperature: Displays the water temper-
ature of the water surface (L TEMP) in degrees
Celsius (°C) or Fahrenheit (°F).
Exterior Temperature: Displays the exterior air
temperature (E TEMP) in degrees Celsius (°C) or
Fahrenheit (°F).
Trip Hour Meter: (TRIPMTR) Allows to measure
an interval of time in hours and minutes (hh:mm).
UNITS AND MESSAGE SECTION
This section shows the units related to the num-
bers displayed. Units such as KMH (MPH), HOUR
etc. are displayed.
Also, whenever one of the following circum-
stances occurs, the following messages will blink
in the message section. The abbreviations be-
tween parenthesis here are the code displayed:
• engine or exhaust system overheating
(H-TEMP)
• low oil pressure (OIL)
• low battery voltage (12 V LOW)
• high battery voltage (12 V HI)
• low fuel level (FUEL-LO)
• maintenance reminder (MAINT)
• check engine (CHK ENG)
• sensor failure (vehicle electronic equipment)
(SENSOR)
• invalid safety lanyard (KEY)
• safety lanyard, learning key active (L KEY)
• end of faults (END).
The red warning LED (Light-Emitting Diode) blinks
along with the beeper to catch your attention.
Except for low liquid levels, which can be correct-
ed by refilling, it is recommended to see an autho-
rized Sea-Doo dealer when other messages occur.
NOTE: If a fault occurs, this system generates
numbered fault codes (P-XXXX) that can be dis-
played through the information center using a spe-
cial procedure. In case of a failure, refer to DI-
AGNOSTIC PROCEDURES in ENGINE MANAGE-
MENT.
When the watercraft is due for a maintenance in-
spection, the message MAINT will blink. After-
wards, it will blink at every start-up for 10 seconds.
After servicing, ensure to clear it.
VTS INDICATOR
RXP Models
The VTS position indicator shows the riding atti-
tude of the watercraft.
174 smr2005-018
