Sea-doo 2005 4-Tec models User Manual

Section 11 ELECTRICAL CONNECTORS AND WIRING DIAGRAMS
Subsection 02 (WIRING DIAGRAMS)
WIRING DIAGRAMS
NOTE: For wiring diagrams, refer to the end of the
manual.
WIRE COLOR CODES
YL - BK
1 2
smr05-026-002_a
1. Wire main color
2. Tracer (thin colored line)
General Wire Color Use
COLOR USE
RED Battery power (12 Vdc directly
connected to battery)
RED + tracer Fused 12 Vdc (from battery)
PURPLE
Continuous power (when there
is a programmed key on DESS
post)
PURPLE + tracer
Switched power (when there
is a programmed key on DESS
post)
BLACK Ground
BLACK + tracer Switched ground (by DESS
post, MPEM, ECM)
WIRE DIGIT CODES
2 - 15 A
1 2 3
smr05-026-001_a
1. Connector the wire is plugged in
2. Position number of the wire in the connector
3. Common circuit in the MPEM with another wire having
the same letter (if applicable)
NOTE: MPEM connectors are numerals (1, 2, etc.)
and ECM connectors identification are letters (A,
B, etc.).
smr2005-026 307
www.SeaDooManuals.net

Sea-doo 2005 4-Tec models Specifications

General

Displacement	1494 cc
Fuel Type	Unleaded gasoline
Engine Type	4-TEC
Cooling System	Closed-loop cooling
Seating Capacity	3
Width	48 inches (122 cm)
Fuel Capacity	15.9 US gallons
