Sea-doo 2005 4-Tec models User Manual

Section 08 STEERING SYSTEM
Subsection 02 (OFF-POWER ASSISTED STEERING SYSTEM (O.P.A.S.))
GENERAL
The Off-Power Assisted Steering (O.P.A.S.) sys-
tem uses a dual side vanes design that assists the
watercraft steering in deceleration, to redirect wa-
tercraft path when steering is turned after throttle
has been released or engine stopped.
The side vanes on the rear sides of the hull, turn
as the steering is turned to assist the watercraft
turning. At first, carefully experiment turning with
this system.
1
F18K03A
1
1. Side vanes turn following steering movement
GTX Series, Wake and RXT Models
When engine is running at approximately 75% or
more RPM, the side vanes are automatically raised
to upper position since they are not required at
that vehicle speed range.
Between 30% and 75% engine RPM, side vanes
are gradually raised from lower position to upper
position.
F18K02A
1
1. Side vane in upper position
When throttle is released and engine RPM drops,
the side vanes are automatically lowered thus as-
sisting steering control.
1
F18K01A
1. Side vane in lower position
RXP Models
These models do not have any vertical travel.
SIDE VANE
Removal
Removal procedure for RH and LH side vane no. 1
is same.
Remove socket screw no. 2.
242 smr2005-039
www.SeaDooManuals.net

Sea-doo 2005 4-Tec models Specifications

General

Displacement	1494 cc
Fuel Type	Unleaded gasoline
Engine Type	4-TEC
Cooling System	Closed-loop cooling
Seating Capacity	3
Width	48 inches (122 cm)
Fuel Capacity	15.9 US gallons
