Sea-doo 2005 4-Tec models User Manual

Section 10 TECHNICAL SPECIFICATIONS
Subsection 02 (GTX LIMITED AND RXT MODELS)
PROPULSION GTX LIMITED RXT
Propulsion system
BOMBARDIER Formula pump
Jet pump type
Axial flow single stage. Greased bearings
Impeller rotation (seen from rear) Counterclockwise
Transmission Direct drive
Coupling type Crown splines
Reverse system Yes
O.P.A.S. system
Yes
Grease type
Jet pump bearing grease
Steering nozzle pivoting angle
20°
Minimum required water level 90 cm (35 in) underneath the lowest rear portion of hull
Drive shaft deflection (maximum) 0.5 mm (.020 in)
Impeller outside diameter 159.0 ± 0.06 mm (6.26 ± .0024 in)
New 0 - 0.23 mm (0 - .009 in)
Impeller/wear ring clearance
Wear limit 0.35 mm (.0138 in)
Impeller shaft end play (new) 0
Impeller shaft side play 0
Impeller material Stainless steel
ADDITIONAL INFORMATION:
DIMENSIONS GTX LIMITED RXT
Number of passenger (driver incl.) 3
Overall length 331 cm (130 in)
Overall width 122 cm (48 in)
Overall height
113 cm (44 in)
Dry weight 397 kg (875 lb) 394 kg (869 lb)
Load limit (passenger and 10 kg (22 lb) luggage) 272 kg (600 lb)
ADDITIONAL INFORMATION:
CAPACITIES GTX LIMITED RXT
Engine oil
3L(2.7U.S.qt)
oil change w/filter: 4.5 L (4.1 U.S. qt) total
Cooling system (coolant) 5.5 L (4.8 U.S. qt) total
Fuel tank (including reserve)
60L(15.9U.S.gal)
Fuel tank reserve (from low level signal) 15L(4U.S.gal)
ADDITIONAL INFORMATION:
MATERIALS GTX LIMITED RXT
Hull
Composite fiberglass
Inlet grate Aluminum
Steering cover Thermoplastic
Impeller housing/stator Aluminum/aluminum
Venturi/nozzle Aluminum/aluminum
Fuel tank Polyethylene
Seat
Polyurethane foam
ADDITIONAL INFORMATION:
smr2005-025 289
www.SeaDooManuals.net

Sea-doo 2005 4-Tec models Specifications

General

Displacement	1494 cc
Fuel Type	Unleaded gasoline
Engine Type	4-TEC
Cooling System	Closed-loop cooling
Seating Capacity	3
Width	48 inches (122 cm)
Fuel Capacity	15.9 US gallons
