Servotronix CDHD Series - Regenerat Ion Resist Ence Calculat Ions

Drive Setup CDHD
116 User Manual
To determine whether a system requires a regeneration resistor, and if so, the
level of capacity, refer t o t he section Regenerat ion Resistance Calcuations t o
calculate system properties.
Figur e 5 - 2 9 . Re genera t ion Resistor Cir cuit
5 .9 .2 Rege neration Resiste nce Calcu lation s
CD H D Bu s Spe cificat ions
Ta ble 5 - 5 4 . Bus Specifica t ions - Single Phase 1 2 0/ 2 4 0 L- L VAC
Drive Mode l
Capacita n ce
( µ F)
V
N OM
( V D C) V
Lo w
( VD C) V
H ig h
( VD C) V
M AX
( VD C)
CDHD-1D5 360 170/ 340 380 400 420
CDHD-003 660 170/ 340 380 400 420
CDHD-4D5 1120 170/ 340 380 400 420
CDHD-006 1120 170/ 340 380 400 420
CDHD-008 2110 170/ 340 380 400 420
CDHD-010 2110 170/ 340 380 400 420
Ta ble 5 - 5 5 . Bus Specifica t ions - Three Ph ase 1 2 0 / 2 4 0 L- L VAC
Drive Mode l
Capacita n ce
( µ F)
V
N OM
( V D C) V
Lo w
( VD C) V
H ig h
( VD C) V
M AX
( VD C)
CDHD-4D5 1120 170/ 340 380 400 420
CDHD-006 1120 170/ 340 380 400 420
CDHD-008 2110 170/ 340 380 400 420
CDHD-010 2110 170/ 340 380 400 420
CDHD-013 2110 170/ 340 380 400 420
CDHD-020 3280 170/ 340 380 400 420
CDHD-024 3280 170/ 340 380 400 420
