CDHD Diagnostics and Troubleshooting
User Manual 235
ERR # Error M essa ge
ERR 314 BiSS-C: Illegal request
ERR 315 BiSS-C: EEPROM save failed
ERR 316 BiSS-C: busy tim eout
ERR 317 BiSS-C: int ernal error
ERR 318 BiSS-C: prot ocol error
ERR 319 BiSS-C: driver error
ERR 320 BiSS-C: driver acquisition tim eout
ERR 321 BiSS-C: driver is occupied
ERR 322 BiSS-C: request CRC error
ERR 324 HI PERFACE data error. Use HSAVE 1.
ERR 325 Predefined and set automatically
ERR 326 Not allowed in DDHD
ERR 328 No serial Enable in COMMODE= 1
1 0 .4 Fie ldbus Sta tus – LEDs
1 0 .4 .1 CAN open
I nt erfaces C5 and C6 ( on AF m odels) share a LED t hat indicates the fieldbus
st atus when communicating on a CANopen network :
Gree n:
Stea dily lit – Operational (OP) state
Fast flashin g – Pre-Operational (PREOP) state
Slow flashing – Stopped st at e
Red:
Flash ing – Error
1 0 .4 .2 Et herCAT
I nt erfaces C5 and C6 (on EB and EC m odels) each have two LEDs that indicate
the fieldbus status when com municating on an EtherCAT network:
Gree n:
Flashing – Communication activity
N ot lit – No comm unication activity
Or a n ge :
Stea dily lit – Operational (OP) state
Slow flashing – Safe-Operation (SAFEOP) state
Fast flashin g – Pre-Operational (PREOP) state
Ve r y fa st flashin g – Boot st rap (BOOT) st ate
N ot lit – Initial (I NIT) state
