1 1 .3 D9 - RJ4 5 Adapt er
Many PLC devices use D9 type interfaces for CAN connections.
To enable the connection of t he CDHD RJ45 port to a D9 interface, Servotronix
offers an adapter, as shown below.
Figur e 1 1 - 1 . D 9 - RJ4 5 Ada pte r
Figur e 1 1 - 2 . D 9 - RJ45 Adapte r I nte r faces
Ta ble 1 1 - 4 . D9 - RJ4 5 Ada pter W iring
Fun ct ion CD HD RJ4 5 Pin D 9 Connector Pin
CAN High 1 7
CAN Low 2 2
Functional Ground 3 3
CAN Shield 6 5
Functional Ground 7 6
