Servotronix CDHD Series - CDHD 7-Segment Code Descriptions

CDHD Diagnostics and Troubleshooting
User Manual 237
1 0 .6 7 - Segm ent Code Description s
The 7-segm ent code descriptions are presented here in alphanum erical order, in
the following form at :
pictu re
of code
code in
text
How displayed (e.g., flashing)
D e finit ion Short nam e. Used in ServoStudio.
Type
Specifies the type of status or fault indicated by the code:
M ode , W arn ing, Fau lt or Fat a l fault.
Act ive disa ble
Indicates whether the Active Disable function (part of
Disable m ode) can be triggered by the fault.
M e ssage # Fault/ Warning/Error code displayed in Terminal.
Descr iption Describes the status or fault indicated by the code.
Action required
Describes the recommended steps for correcting the
fault.
- 5 M otor Se tup Failed
-5 Displayed in sequence
D e finit ion Motor Set up Failed
Type Fault
Act ive disa ble No
M e ssage # FLT 44
Descr iption
Motor Setup procedure failed. MOTORSETUPST will show
the cause.
This fault disables the drive.
Action required
Check phase and motor wiring. Make sure the correct
feedback type is select ed. Check MOTORSETUPST for
hints.
