Servotronix CDHD Series - Fieldbus Devices - C5 and C6

Drive Setup CDHD
98 User Manual
Ta ble 5 - 2 9 . Mot or Br a ke Cont rol M a ting Connector
I te m All M ode ls
Manufacturer Molex*
Housing and
4-pin crimp
436450300* and
0430300001*
Wire gauge 26–28 AWG
* Or equivalent.
C4 - M otor Brake 2 4 VDC I nput
The int erface is labeled C4 on all PB m odels (power blocks).
Ta ble 5 - 3 0 . Mot or Brake 2 4 VDC I nput I nterface
Pin Pin La bel Fun ct ion
1 24VI N + 24V DC
2 24RTN -24V DC
Ta ble 5 - 3 1 . Mot or Brake 2 4 VDC I nput Ma t ing Conn ect or
I te m All M ode ls
Manufacturer Molex*
Housing and
4-pin crimp
436450200* and
0430300001*
Spring term inal Not available
Wire gauge 26–28 AWG
* Or equivalent.
5 .6 .6 Fieldbus Devices – C5 and C6
I nterfaces C5 and C6 are RJ45 port s that serve as transm itt er (Tx) and receiver
(Rx) for drives operating on a CAN or Ethernet network.
Figur e 5 - 1 0 . Fie ldbus Com m unicat ion Por ts
The LEDs on interfaces C5 and C6 indicate fieldbus status. Refer to the section
Fieldbus Status – LEDs.
Refer to the CDHD Et herCAT and CANopen Reference Manual for details on
installation, configuration and operation of drives being used on CAN and
Et herCAT networks.
An adapt er is available t o enable the connection of a RJ45 port to a D9 int erface.
Refer to the section D9 - RJ45 Adapter.
