CDHD Specificat ions
User Manual 27
Ta ble 3 - 5 . M e ch a n ical & Ele ctrical Spe cificat ions –
CD H D - 0 0 3 / CD H D - 0 0 6 / CD H D - 0 1 2 ( 4 0 0 / 4 8 0 VAC)
Three Phase
4 0 0 / 4 8 0 V AC
Spe cifica t ion CDH D - 0 0 3 * CD H D - 0 0 6 * CDH D- 0 1 2
Ra tings
Input Power Circuit
(L1, L2)
Voltage (VAC Line- Line) Nom inal ± 10% 380/ 480 380/ 480 380/ 480
Line Frequency (Hz) 50/ 60 50/ 60 50/ 60
380/ 480 VAC 3 Phase 3 Phase 3 Phase
Continuous Current ( 3 ph A rms)
2.8@400V,
2.3@480V
5.7@400V ,
4.6@480V
11.0@400V
9.2@480V
Line Fuses (FRN-R, LPN, or equivalent)
(A)
10 10 16
Withstand Voltage (Prim ary to Earth)
1800 VAC
(2520 VDC)
1800 VAC
(2520 VDC)
1800 VAC
(2520 VDC)
Control Circuit Input
Power (P2)
24 VDC ± 10%
24 VDC
± 10%
24 VDC
± 10%
24 VDC
± 10%
STO (Safe Torque Off) STO Power Supply (VDC) 24 ± 10% 24 ± 10% 24 ± 10%
Mot or Output ( U, V, W) Continuous Output Current ( A rm s) 3.0 6.0 12.0
Continuous Output Current ( A peak) 4.24 8.48 16.97
Peak Output Current (A rms) for
2 seconds
9 18 24
Peak Output Current (A peak) for
2 seconds
12.72 25.45 33.84
kVA at 380 VAC 1.63 3.11 6.22
kVA at 480 VAC 1.77 3.68 7.36
PWM Frequency (kHz) 8 8 8
Soft Start Max. Surge Soft St art Current ( A) 7 7 9
Max. Charge Tim e (ms) 1300 1300 1300
Power Circuit Loss W
Control Circuit Loss W 5 5 5
Total Power Loss W
H ar d w a r e
Unit Weight kg 2.1 2.1 3.2
Connection Hardware PE Ground Screw Size/ Torque M4/ 1.35 Nm M4/ 1.35 Nm M4/ 1.35 Nm
Wire Size Control Circuit ( AWG) up to 3 met ers 24-28 24-28 24- 28
Main Circuit Motor Lines (AWG) 12- 14 12-14 12-14
Main Circuit AC Input s (AWG) 12-14 12-14 12-14
PE Ground Screw M4 M4 M4
Clearance Distance Side-to- Side (m m ) 25 25 25
Top/ Bottom (m m ) 50 50 50
Volt a g e Trip
Under-Voltage Trip (Nom inal) (VDC) 320 320 320
Over-Voltage Trip (VDC) 800 800 800
