Diagnostics and Troubleshooting CDHD
282 User Manual
r4 3 HI PERFACE Dat a Error
r43 Displayed in sequence
D e finit ion HI PERFACE encoder data error.
Type Fault
Act ive disa ble No
M e ssage # FLT 103
Descr iption This fault disables the drive.
Action required Ent er the com m and HSAVE 1.
r4 5 MEN CZPOS Mism at ch w ith Halls
r45 Displayed in sequence
D e finit ion MENCZPOS Does Not Match Halls
Type Fault
Act ive disa ble No
M e ssage # FLT 111
Descr iption
Either an incorrect MENCZPOS value was saved or the
encoder has a different index location.
The fault is declared when the difference bet ween the
electrical angle based on MENCZPOS and the electrical
angle of t he Hall sensors is greater than 30 degrees.
This fault disables the drive.
Action required
Run Motor Setup wizard and save the new value of
MENCZPOS.
