CDHD Specificat ions
User Manual 29
Ta ble 3 - 6 . M e ch a n ical & Ele ctrical Spe cificat ions –
CD H D - 0 2 4 / CD H D - 0 3 0 ( 4 0 0 / 4 8 0 VAC)
Three- Phase
4 0 0 / 4 8 0 V AC
Spe cifica t ion CD H D - 0 2 4 CD H D - 0 3 0
Ra tings
Input Power Circuit
(L1, L2, L3)
Voltage (VAC Line- Line) Nom inal ± 10% 380/ 480 380/ 480
Line Frequency (Hz) 50/ 60 50/ 60
380/ 480 VAC 3 Phase 3 Phase
Continuous Current (3 ph A rms) 24 30
Line Fuses (FRN- R, LPN, or equivalent) (A) 30 35
Withstand Voltage ( Primary to Earth)
1800 VAC
(2520 VDC)
1800 VAC
(2520 VDC)
Control Circuit Input
Power (P2)
24 VDC ± 10% 24 VDC ± 10%
24 VDC
± 10%
STO and STO2 (Safe
Torque Off)
STO Power supply (VDC) 24 ± 10% 24 ± 10%
STO Fuse (Tim e Delay) 24 VDC ± 10% 1.5 1.5
Mot or Output ( U, V, W) Continuous Output Current ( A rm s) 24 30
Continuous Output Current (A peak) 33.94 42.3
Peak Output Current (A rms) for 3 seconds 72 90
Max Peak Output Current (A peak) for 2 seconds 102 126
kVA at 380 VAC 12.2 15.1
kVA at 480 VAC 15.4 19.0
PWM Frequency (kHz) 8 8
Soft Start Max. Surge Soft Start Current (A) 10 10
Max. Charge Time (ms) 1500 1500
Power Circuit Loss W
Control Circuit Loss W 5 5
Total Power Loss W
H ar d w a r e
Unit Weight kg 10.5 10.5
Connection Hardware PE Ground Screw Size/ Torque M4/ 1.35 Nm M4/ 1.35 Nm
Wire Size Control Circuit ( AWG) up to 3 met ers 24-28 24-28
Main Circuit Motor Lines ( AWG) 12 10
Main Circuit AC Inputs (AWG) 12 10
PE Ground Screw M4 M4
Clearance Dist ance Side- to-Side (mm ) 30 30
Top/ Bottom (m m ) 50 50
Volt a g e Trip
Under-Volt age Trip (nom inal) (VDC) 320 320
Over-Voltage Trip (VDC) 800 800
