SICK FLOWSIC100 User Manual

Specification
FLOWSIC100 · Operating Instructions · 8012513/YSA5/V 2-1/2016-07 · © SICK Engineering GmbH 171
Subject to change without notice
Fig. 138 FLSE100-SA
Fig. 139 FLSE100-SD
NL = 125 mm, 200 mm, 350 mm **
Ø 75*
Ø 100*
A
A
A-A
Ø 35
60 NL
Designation Part No.
FLSE100-SA 12SSTI sender/receiver unit 1043745
FLSE100-SA 20SSTI sender/receiver unit 1043749
FLSE100-SA 35SSTI sender/receiver unit 1043746
Ø 75*
Ø 100*
NL = 125 mm, 200 mm, 350 mm **
A
A
A-A
Ø 35
120
60 132 NL
*: Deliverable with pitch diameter 100 mm
and flange diameter 125 mm on request
Designation Part No.
FLSE100-SD 12SSTI sender/receiver unit 1043742
FLSE100-SD 20SSTI sender/receiver unit 1043747
FLSE100-SD 35SSTI sender/receiver unit 1043743
**: Other nominal lengths on request
