SICK FLOWSIC100 User Manual

24 FLOWSIC100 · Operating Instructions · 8012513/YSA5/V2-1/2016-07 · © SICK Engineering GmbH
Product Description
Subject to change without notice
Fig. 8 FLSE100-PR
Fig. 9 FLSE100-SA
Fig. 10 FLSE100-SD
A - A
NL = 350 mm, 550 mm, 750 mm
A
A
NL
1
2
3
4
5
A
A
NL
A - A
NL = 125 mm, 200 mm, 350 mm
2
3
4
5
NL
A
A
A - A
NL = 125 mm, 200 mm, 350 mm
1 Electronics unit 4 Transducer
2 Connection piece 5 Connection for connection cable
3 Duct probe
1
2
4
5
3
