32 FLOWSIC100 · Operating Instructions · 8012513/YSA5/V2-1/2016-07 · © SICK Engineering GmbH
Product Description
Subject to change without notice
Control unit MCU in 19” enclosure with options
SICK
M
ULTI
C
ONTROL
U
NIT
POWER
FAILURE
MAINTENANCE
REQUEST
INTERFACE-MODULE
I/O-MODULE
POWER
ERROR
TxD RxD
Slots for optional I/O modules
Backplane with terminal connections for wiring by customer
Power
Slot for interface module option
Display module option
