Product Description
FLOWSIC100 · Operating Instructions · 8012513/YSA5/V2-1/2016-07 · © SICK Engineering GmbH 33
Subject to change without notice
Block Diagram
Fig. 19 MCU block circuit diagram
MCU
Relay 5
Relay 4
Relay 3
Relay 2
Relay 1
Processor
Optional I/O module(s)
Display module option
Interface module option
RS232
USB 1.1
Analog
inputs
1 and 2
Analog
output
Digital
inputs
1 to 4
Wide-range
power pack
Relays
1 to 5
90 ... 250 V AC
