SICK FLOWSIC100 User Manual

Assembly and Installation
FLOWSIC100 · Operating Instructions · 8012513/YSA5/V2-1/2016-07 · © SICK Engineering GmbH 59
Subject to change without notice
Correlation between inside diameter Di and measuring path L depending on draw-in
length Le and installation type (dimensions in m):
Di Measuring path L at a = 60°, Le = ... and installation across
Diameter Secant
Le=0.05 Le=0.10 Le=0.15 Le=0.20 Le=0.25 Le=0.30 Le=0.35 Le=0.40 Le=0.45 Le=0.50 Le=0.50 a
max
1.00 1.01
1.05 1.07
1.10 1.13 1.03
1.15 1.18 1.08
1.20 1.24 1.14 1.04
1.25 1.30 1.20 1.10 1.00
1.30 1.36 1.26 1.16 1.06
1.35 1.41 1.31 1.21 1.11 1.01
1.40 1.47 1.37 1.27 1.17 1.07
1.45 1.53 1.43 1.33 1.23 1.13 1.03
1.50 1.59 1.49 1.39 1.29 1.19 1.09
1.55 1.65 1.55 1.45 1.35 1.25 1.15 1.05
1.60 1.70 1.60 1.50 1.40 1.30 1.20 1.10 1.00
1.65 1.76 1.66 1.56 1.46 1.36 1.26 1.16 1.06
1.70 1.82 1.72 1.62 1.52 1.42 1.32 1.22 1.12 1.02
1.75 1.88 1.78 1.68 1.58 1.48 1.38 1.28 1.18 1.08
1.80 1.93 1.83 1.73 1.63 1.53 1.43 1.33 1.23 1.13 1.03
1.85 1.99 1.89 1.79 1.69 1.59 1.49 1.39 1.29 1.19 1.09
1.90 1.95 1.85 1.75 1.65 1.55 1.45 1.35 1.25 1.15
1.95 2.01 1.91 1.81 1.71 1.61 1.51 1.41 1.31 1.21
2.00 1.97 1.87 1.77 1.67 1.57 1.47 1.37 1.27
2.05 1.92 1.82 1.72 1.62 1.52 1.42 1.32 1.01 0.51
2.10 1.98 1.88 1.78 1.68 1.58 1.48 1.38 1.06 0.53
2.15 1.94 1.84 1.74 1.64 1.54 1.44 1.11 0.54
2.20 2.00 1.90 1.80 1.70 1.60 1.50 1.16 0.55
2.25 1.95 1.85 1.75 1.65 1.55 1.21 0.56
2.30 1.91 1.81 1.71 1.61 1.26 0.58
2.35 1.97 1.87 1.77 1.67 1.31 0.59
2.40 1.93 1.83 1.73 1.36 0.60
2.45 1.99 1.89 1.79 1.41 0.61
2.50 1.94 1.84 1.46 0.63
2.55 2.00 1.90 1.51 0.64
2.60 1.96 1.56 0.65
2.65 1.61 0.66
2.70 1.66 0.68
2.75 1.71 0.69
2.80 1.76 0.70
2.85 1.81 0.71
2.90 1.86 0.73
2.95 1.91 0.74
3.00 1.96 0.75
