SICK FLOWSIC100 User Manual

Assembly and Installation
FLOWSIC100 · Operating Instructions · 8012513/YSA5/V2-1/2016-07 · © SICK Engineering GmbH 65
Subject to change without notice
A selection of values is provided in the following Table. The Table shows that flanges with
tube with the next longest nominal length than that of the sender/receiver units must be
selected.
Matching flanges with tube can be provided by SICK on request (please specify with order).
Alternatively, a tube piece with premounted flanges can be ordered from SICK.
A tube with suitable diameter can be used to align the flange tubes for face-to-face
mounting.
After welding, determine and note measure F-F (
 p. 63, Fig. 36) for later parameter setting.
Tube length L
F
, L
F45
/L
F60
at nominal length NL
NL=125 NL=200 NL=310 NL=350 NL=550
 w x L
F
L
F45
L
F
L
F45
L
F
L
F45
L
F
L
F45
L
F
L
F45
45° 1 26.1 151.1 102.8 226.1 177.8 336.1 287.8 376.1 327.8 576.1 527.8
2 24.7 149.7 101.4 224.7 176.4 334.7 286.4 374.7 326.4 574.7 526.4
3 23.3 148.3 100.0 223.3 175.0 333.3 285.0 373.3 325.0 573.3 525.0
4 21.9 146.9 98.6 221.9 173.6 331.9 283.6 371.9 323.6 571.9 523.6
5 20.4 145.4 97.1 220.4 172.1 330.4 282.1 370.4 322.1 570.4 522.1
6 19.0 144.0 95.7 219.0 170.7 329.0 280.7 369.0 320.7 569.0 520.7
7 17.6 142.6 94.3 217.6 169.3 327.6 279.3 367.6 319.3 567.6 519.3
8 16.2 141.2 92.9 216.2 167.9 326.2 277.9 366.2 317.9 566.2 517.9
9 14.8 139.8 91.5 214.8 166.5 324.8 276.5 364.8 316.5 564.8 516.5
10 13.4 138.4 90.1 213.4 165.1 323.4 275.1 363.4 315.1 563.4 515.1
 w x L
F
L
F60
L
F
L
F60
L
F
L
F60
L
F
L
F60
L
F
L
F60
60° 1 13.7 138.7 110.8 213.7 185.8 323.7 295.8 363.7 335.8 563.7 535.8
2 12.5 137.5 109.6 212.5 184.6 322.5 294.6 362.5 334.6 562.5 534.6
3 11.3 136.3 108.5 211.3 183.5 321.3 293.5 361.3 333.5 561.3 533.5
4 10.2 135.2 107.3 210.2 182.3 320.2 292.3 360.2 332.3 560.2 532.3
5 9.0 134.0 106.1 209.0 181.1 319.0 291.1 359.0 331.1 559.0 531.1
6 7.9 132.9 105.0 207.9 180.0 317.9 290.0 357.9 330.0 557.9 530.0
7 6.7 131.7 103.8 206.7 178.8 316.7 288.8 356.7 328.8 556.7 528.8
8 5.6 130.6 102.7 205.6 177.7 315.6 287.7 355.6 327.7 555.6 527.7
9 4.4 129.4 101.5 204.4 176.5 314.4 286.5 354.4 326.5 554.4 526.5
10 3.3 128.3 100.4 203.3 175.4 313.3 285.4 353.3 325.4 553.3 525.4
