Operation
MCS100E Operating Instructions 8009504/VYWA7/V3-1/2018-01 © SICK AG 95
Subject to change without notice
5.7.15.7.2 Control Detector unit
Specialist: Utilities: Service: Control Detector unit
This menu option contains the display and calibration of the components activated in
“Specialist: System edit: Definition of components” as well as a variety of tests.
At the bottom, left, the measurement cycle time and the component that is being
measured, are displayed.
5.7.15.7.3 Dialogue Detector unit
Specialist: Utilities: Service: Dialogue Detector unit
Dialogue with detector unit: Only for service purposes
ASCII - Hex - switch-over: ALT H
Echo ON/OFF: ALT E
Menu exit: F2 or ALT X
5.7.15.7.4 Dialogue heat control
Specialist: Utilities: Service: Dialogue heat control
Dialogue with heat control: Only for service purposes
ASCII - Hex - switch-over: ALT H
Echo ON/OFF: ALT E
Menu exit: F2 or ALT X
Settings
REF
Meas
Energy of the reference resp. measurement signal in counts, dependent of the gain
factor (i.e. counts increase with the gain factor).
ABS raw Display of absorbance, not corrected.
ABS add Display of additively corrected absorbance.
ABSORB. Display of completely corrected absorbance.
CONCENT Calculated concentration
CALIBRATION Predefined calibration value
Calibration fac-
tor
Upon <ENTER>, the calibration factor is calculated is such a way that the CONCENT.
equals the value pre-defined in CALIBRATION.
ZERO SET Actual value is set to “Zero“
Tst 0 Terminate all switched-on tests.
Tst 1 LPM40 send disable
Tst 2 LPM40 send enable
Tst 3 LPM40 restart
Tst 4 Test signal on. Instead of the detector signal a testsignal is enabled for the pre-
amplifier.
Tst 5 Test signal off.
Disables the test signal enabled in test 4.
Tst 6 Determine amplification
Tst 7 Send data to LPM40
Tst 8 No synchronization
Tst 9 .. Tst 15 Not used
Status Detector
0OK
8 Power failure on LPM40
