SICK microScan3 Core I/O AIDA User Manual

microScan3 Core I/O AIDA
Scan cycle time 40 ms 0.125°
Scan cycle time 50 ms 0.1°
Response time
Devices with a max. protec‐
t
ive field range of 4.0 m
≥ 70 ms, details: see "Response times", page 131
Devices with a max. protec‐
tive field range of 5.5 m
≥ 70 ms, details: see "Response times", page 131
Devices with a max. protec‐
tive field range of 9.0 m
≥ 90 ms, details: see "Response times", page 131
Scan cycle time
Devices with a max. protec‐
t
ive field range of 4.0 m
30 ms or 40 ms (adjustable)
Devices with a max. protec‐
tive field range of 5.5 m
30 ms or 40 ms (adjustable)
Devices with a max. protec‐
t
ive field range of 9.0 m
40 ms or 50 ms (adjustable)
Generally necessary protective field supplement (TZ = tolerance zone of the safety laser
scanner)
Devices with a max. protec‐
tive field range of 4.0 m
65 mm
Devices with a max. protec‐
t
ive field range of 5.5 m
65 mm
Devices with a max. protec‐
tive field range of 9.0 m
100 mm
Additional supplement
Z
R
f
or reflection-based meas‐
urement errors
350 mm
Deviation from ideal flatness
of sc
an field at 5.5 m
2)
≤ ± 100 mm
Deviation from ideal flatness
of scan field at 9.0 m
3)
≤ ± 100 mm
Distance of mirror rotational
a
xis (zero point of x and y
axis) to rear side of device
56 mm
Distance between center
point of scan plane and top
edge of the housing
40 mm
Multiple sampling 2 … 16
1)
Protective field resolution 60 mm only available for devices with max. protective field range of 9.0 m.
2)
Devices with a max. protective field range of 4.0 m and devices with max. protective field range of 5.5 m
3)
Devices with a max. protective field range of 9.0 m.
Safety-related parameters
T
able 23: Safety-related parameters
microScan3 Core I/O AIDA
Type Type 3 (IEC 61496)
Safety integrity level SIL 2 (IEC 61508)
SIL claim limit SILCL 2 (IEC 62061)
Category Category 3 (ISO 13849-1)
Performance level PL d (ISO 13849-1)
TECHNICAL DATA 13
8017784/1ELL/2022-01-21 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 Core I/O AIDA
127
Subject to change without notice

SICK microScan3 Core I/O AIDA Specifications

General

Scanning angle	275°
Protection class	IP65
Configuration method	SOPAS ET
Enclosure rating	IP65
Dimensions	102 mm x 152 mm x 106 mm
Scanning range	5.5 m
Protective field range	5.5 m
Number of monitoring cases	128
Supply voltage	24 V DC
Performance level	PL e (ISO 13849-1)
Warning field range	5.5 m
Resolution for safety field	30 mm / 40 mm / 50 mm / 70 mm
Connection type	M12
Protective field resolution	30, 40, 50, 70 mm
Number of protective fields	128
