microScan3 Core I/O AIDA
Standards
•
IE
C 60068-2-6
•
IEC 60068-2-64
•
IEC 60721-3-5
•
IEC TR 60721-4-3
•
IEC 61496-1
•
IEC 61496-3
Class
•
5M1 (IEC 60721-3-5)
•
3M4 (IEC TR 60721-4-3)
Sinusoidal vibrations
•
50 m/s², 0.35 mm, 10 Hz … 150 Hz
•
5 m/s², 1.5 mm, 5 Hz … 200 Hz
•
10 m/s², 3.5 mm, 5 Hz … 150 Hz
Noise vibrations
•
0.5 m²/s³, 5 Hz … 200 Hz
•
0.1 m²/s³, 200 Hz … 500 Hz
Shock resistance
4)
Standards
•
IE
C 60068-2-27
•
IEC 60721-3-5
•
IEC TR 60721-4-3
•
IEC 61496-1
•
IEC 61496-3
Class
•
5M1 (IEC 60721-3-5)
•
3M4 (IEC TR 60721-4-3)
Single shock 50 m/s², 11 ms
Continuous shock
•
100 m/s², 16 ms
•
150 m/s², 6 ms
EMC
5)
In accordance with IEC 61496-1, IEC 61000-6-2, and
IE
C 61000-6-4
1)
The specified enclosure rating is only valid if the safety laser scanner is closed, the system plug is
mount
ed, and all of the M12 plug connectors of the safety laser scanner have been closed using a cable
plug connector or using a protective cap.
2)
For ambient light sources directly in the scan plane in accordance with IEC 61496-3: ≤ 3 klx.
3)
IEC 61496-1, no. 4.3.1 and no. 5.4.2, IEC 61496-3, no. 4.3.1 and no. 5.4.2. Condensation has an
influence on normal operation.
4)
In direct mounting.
5)
In order to reach higher electromagnetic compatibility under rough electromagnetic ambient conditions,
we recommend setting the input filter time of the connected control (on-off filter) to a value ≥ 5 ms.
Please note that this increases the response time of the total system by at least this set filter time.
Miscellaneous data
T
able 28: Miscellaneous data
microScan3 Core I/O AIDA
Wavelength 845 nm
Detectable remission 1.8% … several 1,000%
Maximum uniform contami‐
na
tion of the optics cover
without reducing the detec‐
tion capability
1)
30%
Area where detection capabil‐
it
y is restricted
≤ 50 mm
2)
Light spot size
3)
Devices with a max. protective field range of 4.0 m
At front screen 18 mm × 4 mm
13 TECHNICAL DATA
130
O P E R A T I N G I N S T R U C T I O N S | microScan3 Core I/O AIDA 8017784/1ELL/2022-01-21 | SICK
Subject to change without notice
