microScan3 Core I/O AIDA
Output current for ON state
(H
IGH)
≤ 30 mA per OSSD
Leakage current
3)
≤ 250 µA
Load inductance Does not support inductive loads.
Load capacity ≤ 1 µF in series with 4 Ω
Permissible resistivity
be
tween load and device
≤ 2.5 Ω
Test pulse width ≤ 300 µs (typ. 230 µs)
4)
Test pulse interval
Scan cycle time 30 ms 240 ms … 264 ms (typ. 240 ms)
Scan cycle time 40 ms 320 ms … 344 ms (typ. 320 ms)
Scan cycle time 50 ms 400 ms
Duration of OFF state ≥ 80 ms
Discrepancy time (time
of
fset between switching
OSSDs of an OSSD pair)
≤ 1 ms (typ. 25 µs)
1)
The power supply unit must be able to jumper a brief power failure of 20 ms as specified in
IE
C 60204-1. Suitable power supply units are available as accessories from SICK.
2)
The voltage level must not fall below the specified minimum voltage.
3)
In the event of a fault (interruption of the 0 V cable), the specified leak current at most flows in the OSSD
cable. The downstream control element must detect this state as the OFF state.
4)
In order to reach higher electromagnetic compatibility under rough electromagnetic ambient conditions,
we recommend setting the input filter time of the connected control (on-off filter) to a value ≥ 5 ms.
Please note that this increases the response time of the total system by at least this set filter time.
Mechanical data
T
able 26: Mechanical data
microScan3 Core I/O AIDA
Dimensions (W × H × D) 112 mm × 135.1 mm × 111.1 mm
Weight (including system
plu
g)
1.15 kg
Housing material Aluminum
Housing color RAL 9005 (black) and RAL 1021 (colza yellow)
Optics cover material Polycarbonate
Optics cover surface Outside with scratch-resistant coating
Ambient data
T
able 27: Ambient data
microScan3 Core I/O AIDA
Enclosure rating
1)
IP65 (IEC 60529)
Ambient light immunity ≤ 40 klx
2)
Ambient operating tempera‐
t
ure
–10 °C … 50 °C
Storage temperature –25 °C … 70 °C
Air humidity ≤ 95%, non-condensing
3)
Height above sea level during
operation
≤ 2300 m
Vibration resistance
4)
TECHNICAL DATA 13
8017784/1ELL/2022-01-21 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 Core I/O AIDA
129
Subject to change without notice

SICK microScan3 Core I/O AIDA Specifications

General

Scanning angle	275°
Protection class	IP65
Configuration method	SOPAS ET
Enclosure rating	IP65
Dimensions	102 mm x 152 mm x 106 mm
Scanning range	5.5 m
Protective field range	5.5 m
Number of monitoring cases	128
Supply voltage	24 V DC
Performance level	PL e (ISO 13849-1)
Warning field range	5.5 m
Resolution for safety field	30 mm / 40 mm / 50 mm / 70 mm
Connection type	M12
Protective field resolution	30, 40, 50, 70 mm
Number of protective fields	128
