SICK microScan3 Core I/O AIDA User Manual

16 Accessories
16.1 Brackets
Table 37: Brackets ordering information
Part Part number
Mounting kit 1a 2073851
Mounting kit 1b (with protection for optics cover) 2074242
Mounting kit 2a (alignment bracket, alignment with cross-wise axis and
dept
h axis possible, distance between mounting surface and device:
22.3 mm, only in conjunction with mounting kit 1a or 1b)
2073852
Mounting kit 2b (alignment bracket, alignment with cross-wise axis and
depth axis possible, distance between mounting surface and device:
52.3 mm, only in conjunction with mounting kit 1a or 1b)
2074184
Bracket for floor mounting, 150 mm 2112950
Bracket for floor mounting, 300 mm 2112951
Heavy duty mounting kit 2102289
16.2 Alignment aid
Table 38: Alignment aid ordering information
Part Type code Part number
Alignment aid 2101720
16.3 Cleaning agent
Table 39: Cleaning agent ordering information
Part Part number
Anti-static plastic cleaner 5600006
Lens cloth 4003353
16.4 Test rods
Table 40: Ordering information, test rods
Part Part number
Test rod 50 mm 2095105
Test rod 70 mm 2095139
Test rod holder 4096204
ACCESSORIES 16
8017784/1ELL/2022-01-21 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 Core I/O AIDA
137
Subject to change without notice

SICK microScan3 Core I/O AIDA Specifications

General

Scanning angle	275°
Protection class	IP65
Configuration method	SOPAS ET
Enclosure rating	IP65
Dimensions	102 mm x 152 mm x 106 mm
Scanning range	5.5 m
Protective field range	5.5 m
Number of monitoring cases	128
Supply voltage	24 V DC
Performance level	PL e (ISO 13849-1)
Warning field range	5.5 m
Resolution for safety field	30 mm / 40 mm / 50 mm / 70 mm
Connection type	M12
Protective field resolution	30, 40, 50, 70 mm
Number of protective fields	128
