SICK S3000 User Manual

Chapter 12 Operating instructions
S3000
148 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8009942/WK81/2012-11-28
Subject to change without notice
Technical specifications
Minimum Typical Maximum
Sender Pulsed laser diode
Wavelength 880 nm 905 nm 935 nm
Divergence of the collimated beam 2.5 mrad
Pulse duration 3.1 ns
Average output power 562 µW
Size of light spot at the front screen 12 mm
Size of the light spot at 4.0 m scanning
range
23 mm
Size of the light spot at 5.5 m scanning
range
27 mm
Size of the light spot at 7.0 m scanning
range
32 mm
Housing
Material Aluminium die-cast
Color RAL 1021 (rapeseed yellow)
Front screen
Material Polycarbonate
Surface finish Outside with scratch-resistant coating
System plug ESD protected
Dimensions S3000
31)
Height 185 mm
Width 155 mm
Depth 160 mm
Total weight 3.3 kg
Functional data
Resolution 30, 40, 50, 70, 150 mm
Protective field of the sensor head with 4.0 m
scanning range
32)
at 120 ms response time
At 30 mm resolution 2.80 m
At 40 mm resolution 3.80 m
At 50 mm resolution 4.00 m
At 70 mm resolution 4.00 m
At 150 mm resolution 4.00 m
31)
Without projection of cable glands with system plug mounted.
32)
Radial distance to the safety laser scanner.
