SICK S3000 User Manual

Operating instructions Chapter 5
S3000
8009942/WK81/2012-11-28 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 71
Subject to change without notice
Mounting
How to calculate the supplement C:
 If there is enough empty space in front of your machine or system, use 1200 mm for the
s
upplement C.
 If the minimum distance is to be kept as small as possible, calculate C using the
following formula:
C = 1200 mm – (0.4 × H
D
)
Here H
D
is the height at which the protective field is mounted.
The minimum supplement to prevent reaching over is 850 mm (arm length).
In summary there are three usual mounting variants for the scan plane of the S3000. The
optimal variation depends on the related application.
Tab. 20 provides assistance making the selection.
Mounting orientation Benefit Disadvantage
Scanner low (H
S
< 300 mm)
Low inclination of the scan
plane (H
D
 H
S
)
No external effects due to
dazzle, crawling beneath
not possible
Larger supplement C
Scanner high (H
S
> 300 mm)
Low inclination of the scan
plane (H
D
 H
S
)
Lower protective field
supplement C
Danger of crawling be-
neath (at the front and
side)
Scanner low (H
S
< 300 mm)
High inclination of the scan
plane (H
D
> H
S
)
Lower protective field
supplement C
Danger of crawling be-
neath (at the front),
external effect due to
dazzle possible
Note
Fig.
32
:
Mounting variations
for the scan plane
Tab.
20
:
Advantages and
disadvantages of mounting
variations
H
D
= Detection height
H
S
= Scanner mounting
height
C
C
C
H
D
H
D
H
S
H
S
H
D
H
S
