Sicma TR80 - Greasing of the Vibrating Head Oscillation Jack Pins

Maintenance
6.11.4 Greasing of the vibrating head oscillation jack pins
Proceed as follows to grease the pins of the vibrating head jack:
A) Use the controls on the remote control to lower the arm just enough to
allow greasing from the ground.
B) Safely stop the machine. (*).
C) To grease it is necessary to use the prepared grease nipples; inject
lubricating grease in the points indicated in Figure 82.
(*) See par. “5.7” pag. 99
Figure 82
139
