Machine description and technical information
3.4.4 Electrical system
The machine has a 12 V electrical system; for the use of this system it is
necessary to connect the specific electrical socket to the tractor.
NOTE
For further details, refer to the wiring diagrams of the machine attached to
the manual.
Main components
1) Remote control
2) Electric socket (12 V) for connection to the tractor
3) Electric fuse holder
4) Remote control wireless signal receiving unit
1
2
4
3
Figure 13
