User and maintenance manual - SEMI-MOUNTED HARVESTER WITH TRUNK SHAKER - TR80
Rev. 0 - 05/2021
5.2 Uncoupling from the tractor
Follow the procedure below to disconnect the machine:
• Check that there are no obstacles in the parking area.
• Use the radio control to bring the vibrating head to rest on the ground.
• Turn off the remote control by turning the main selector (battery switch)
anticlockwise.
• Set the tractor engine to idling speed and leave it running for as long
as it takes for the PTO to reach minimum revs.
• Disengage the PTO.
• Stop the operating machine safely (engine off, ignition key removed
and parking brake applied).
• Disconnect the quick couplings (1) from the tractor.
1
1
Figure 47
Figure 48
80
