Sicma TR80 - Size in Transport Configuration

User and maintenance manual - SEMI-MOUNTED HARVESTER WITH TRUNK SHAKER - TR80
Rev. 0 - 05/2021
3.5.2 Size in transport configuration
NOTE
The dimensions shown in the figure are in millimeters.
1500
35001330
The harvester is configured as follows:
- Arm fully retracted
- Arm in horizontal position
Figure 17
46
