Sicma TR80 - Features of the Harvester

Machine description and technical information
3.5.4 Features of the harvester
Description Value
Track (mm) See Figure 22
Maximum hydraulic arm extension (mm)
2000
Total weight (kg) 2340
Cardan shaft drive PTO 540 rpm
The machine track width (external tyre – external tyre) can be adjusted to 4
positions by acting on the wheel hubs.
2415 mm*
2315 mm 2215 mm 2115 mm
NOTE (*)
Track adjustment to 2,415 mm is exclusive of the version equipped with
hydraulically controlled braking wheel hubs (optional).
Figure 22
49
SICMA S.r.l.
