User and maintenance manual - SEMI-MOUNTED HARVESTER WITH TRUNK SHAKER - TR80
Rev. 0 - 05/2021
6.10.2 Greasing of jack pins and jaws
The pins of the jacks for opening/closing the jaws are equipped with grease
nipples, as is the central pivot of the jaws.
Inject lubricating grease at the points indicated at Figure 71.
Figure 71
128
