Machine use
5.3.2 Controls on the machine
1
2
REF. DESCRIPTION POSITION FUNCTION
1 Pressure gauge - Indicates the clamping pressure of the jaws of the vibrating head.
2 Knob
rotation to
the right
Increased clamping pressure of the jaws of the vibrating head.
rotation to
the left
Reduction of the clamping pressure of the jaws of the vibrating
head.
NOTE
The ideal clamping pressure should be between 110 and 190 bar.
It is recommended not to work at pressures outside this range to ensure
perfect machine functionality.
Figure 52
89
