6.11.5 Greasing of the joint and vibrating head holder arm
To grease the joint and the vibrating head holder arm, proceed as follows:
A) Use the controls on the remote control to lower the arm just enough to
allow greasing from the ground.
B) Safely stop the machine. (*).
C) To grease the vibrating head holder arm it is necessary to use the grease
nipples provided; inject lubricating grease in the points indicated in
Figure 83 with reference (1).
D) To grease the joint it is necessary to use the predisposed grease nipples;
inject lubricating grease in the points indicated in Figure 83 with the
reference (2).
1
2
(*) See par. “5.7” pag. 99
Figure 83
