Machine use
• Disconnect the three-pole plug from the tractor.
• Disconnect the tie-rod/cylinder of the tractor from the third upper point
(1) of the machine by removing the relative pin, then put it in a safe
place, away from the work area;
• Remove the safety chains of the guard of the cardan shaft then
disconnect it and put it in a safe place, away from the work area.
• Remove the safety pins (4) of the pins (3).
• Remove the pins (3) from the two lower points (2) of the machine and
put them in a safe place, away from the work area, then disconnect
the lower arms of the three-point connection of the tractor, lowering
them;
• Start the tractor and move it away from the machine.
2
3 4
1
Figure 49
81
SICMA S.r.l.
