User and maintenance manual - SEMI-MOUNTED HARVESTER WITH TRUNK SHAKER - TR80
Rev. 0 - 05/2021
5) Fuse (20 Ah) for wireless signal control unit power supply
6) Wireless remote control unit
7) Vibration gear control solenoid valves (1st and 2nd)
8) Upper solenoid valves group
9) Lower solenoid valve group
7
5
6
8
9
10) Solenoid valve block
11) Wireless signal reception antenna
10
11
Figure 14
Figure 15
