User and maintenance manual - SEMI-MOUNTED HARVESTER WITH TRUNK SHAKER - TR80
Rev. 0 - 05/2021
10) Hydraulic oil heat exchanger
11) Speed multiplier gearbox
12) Service pump
12
10
11
13) Block valve and telescopic arm rotation speed
14) Vibrating head pressure gauge connection
15) Vibrating head pressure regulating valve
13
14
15
Figure 11
Figure 12
