User and maintenance manual - SEMI-MOUNTED HARVESTER WITH TRUNK SHAKER - TR80
Rev. 0 - 05/2021
If the electrical socket is inserted correctly, the green LED (2) will light up on
the machine. If otherwise the red LED (2) lights up, check the correct insertion
of the power socket and, if necessary, the electrical system of the tractor.
WARNING
Check the correspondence of the polarity between the socket and the plug.
As long as the red LED (2) remains on, it will not be possible to use the radio
control.
Also check the fuse protecting the radio control unit itself.
2 3 1
Figure 45
78
