User and maintenance manual - SEMI-MOUNTED HARVESTER WITH TRUNK SHAKER - TR80
Rev. 0 - 05/2021
Below is an example of machine operation in a tree with a distance of 6 m
between the rows and 6 m on the row:
- The machine is positioned at the center of the inter-row and through
the rotation and the telescopic extension of the arm reaches the trunk
of the two opposite trees.
- Once the vibration of the two shafts ends, the tractor will move forward
by 6 m facilitating the gripping and subsequent vibration of the two
consecutive shafts on the row.
6 m
6 m
Figure 54
94
