11 'Detection' task card
The following logical elements are shown in the 'Detection' task card:
● ↑ 'Area'
– The 'Area' element is also created when creating a ↑ 'Station'.
– Additional 'Area' elements can be created for each 'Station'.
● ↑ 'Section'
– A 'Section' element is also created when creating a 'Station'.
– Additional 'Section' elements can be created for each 'Station'.
● ↑ 'Zone'
– The 'Zone'element can be created manually.
● ↑ 'Logical channel'
– The 'Logical channel' element can be created manually during ↑ pre-
configuration. But this is not usually necessary because this element is
created when assigning to the corresponding hardware element. If an
↑ assignment is deleted, the channel is retained.
If the control panel is configured using the '
Auto
-
configure line
' (
C
-
NET
lines only)
or 'Auto-configure station' function, the 'Section', 'Zone' and 'Logical channel'
elements are created automatically. The physical and logical channels are
assigned automatically.
You will find more information about the auto-configuration in document
A6V10210416. See chapter 'Applicable documents'.
See also
2 Applicable documents [➙ 13]
11.1 Creating 'Detection tree'
To create the ↑ 'Detection tree', proceed as follows:
1. Select 'Detection' > 'Station' > 'Detection area' > 'Section' in the task card.
2. Use the corresponding template to create a 'Zone' for the 'Section'. Link [➙ 68]
3. Enter customer texts.
When creating the '
Detection tree
', you can use the functions '
CSV export
' and
'CSV import' in order to export and import customer-specific data, e.g. customer
texts. You will find more information on this in chapter 'Exporting and importing
CSVs [➙ 91]'.
See also
2 Exporting and importing CSVs [➙ 91]
