● 'Data bits:': Amount of data for transfer
● 'Stop bits:': Data transfer stop bit
● 'enable DTR': If the checkbox is activated, the ready state of the destination
data terminal will be indicated by an interface control signal.
● 'enable RTS': If the checkbox is activated, the ready state of the sending data
terminal will be indicated by an interface control signal being sent to the
destination data terminal.
The settings of the '
Serial
communication parameters
' do not apply for reading
devices with USB-COM port.
The settings only go into effect when you reopen the '
Assign dialog
' window.
See also
2 Assignment with Data Matrix code [➙ 83]
4.5.5 Editing
The following can be set in the 'Editing' view:
Property / function Value Description
'Ignore mouse wheel' On/off
Ticking the checkbox deactivates the mouse wheel
of the computer mouse. This prevents settings in a
drop-down list being unintentionally changed if you
are scrolling in the detail editor with the mouse
wheel.
The setting '
Ignore mouse wheel
' does not go into effect until you select a new
element in the structure tree. The setting is not yet adopted for the currently
selected element.
See also
2 Entering quicktext [➙ 72]
4.5.5.1 Event text suggestions
The following can be set in the 'Custom event text proposals' view:
Property / function Value Description
'Maximum proposals count' Numerical input field Number of proposed texts that are saved.
'Manage proposals'
'Reset proposals' Button Delete existing proposed texts.
'Edit proposals' Enter or edit proposed texts.
'Import proposals' Import proposed texts in the '.properties' format.
'Export proposals' Export proposed texts in the '.properties' format.
