6.23 Exporting an SIB-X
The SiB-X export function can be used to export the configuration data definitions
into an XML file in SiB-X format. SiB-X is the format for exchanging configuration
data between various products of Siemens Building Technologies,
e.g., Management System MM8000.
Exporting configuration data
NOTICE
Cloud Gateway
FG2004 in the SiB
-
X export dialog not excluded from the export
If you have configured a Cloud Gateway FG2004 for the site and you have not
excluded it from the export, then the management system displays a connection
fault to the Cloud Gateway FG2004 after the import of the SiB-X data.
● Remove the relevant check mark in the export dialog if you have configured a
Cloud Gateway FG2004 for the site.
1. Open a ↑ site using the 'File' > 'New site' or 'Open' menu item.
2. Click on the 'File' > 'SiB-X export' menu item.
a The 'SiB-X export' window opens.
3. Select the 'Stations' you want.
4. Remove the relevant check mark in the export dialog if you have configured a
Cloud Gateway FG2004 for the site.
5. Select the path, enter a file name, and click on 'Start'.
a The configuration data is exported.
