6.25 Change display logo
By default, in the normal state of the ↑ 'Station', the Siemens logo is shown on the
display. You can replace the Siemens logo with a customer specific logo. The logo
must be available as a GIF file and must meet the following requirements:
● Maximum size: 251 x 56 pixels
● Black and white
● No transparency
● Not interlaced
Replacing the standard logo
1. Select 'Edit' > 'Exchange logo in site' from the menu bar.
a The following window is opened:
2. Click on 'OK'.
3. Select the file with the new logo.
4. Load the configuration from the PC to the 'Station'.
a After a restart of the 'Station', the new logo is shown on the display.
Restoring the standard logo
1. Select 'Edit' > 'Exchange logo in site' from the menu bar.
a The following window is opened:
2. Click on 'Reset to default'.
3. Load the configuration from the PC to the 'Station'.
a After a restart of the 'Station', the standard logo is shown on the display.
a The file with the replaced logo is saved in the same folder in which the ↑ 'Site'
configuration is saved.
See also
2 Loading configuration from the PC to the station [➙ 107]
