Creating a 'Station' with an individual address
This function is normally called up when migrating from old systems if a particular
address is to be assigned to a 'Station'.
Once the '
Station
' has been created, the address cannot be changed any more.
The maximum value that can be set for the address of the 'Station' is 250.
1. Select 'Edit' > 'New station with address' from the menu bar.
a The 'New station with address' window opens.
2. Set the desired properties and click on 'Add'.
a The 'Station' is created with the address entered.
See also
2 Creating networked 'Stations' [➙ 312]
6.3 Creating a station with FBP [AU]
l Proceed as described in chapter 'Creating a station [➙ 67]' and select the
'AU FBP - Alarming pre-configured' template.
a A 'Station' with FBP is created.
a The PMI with FBP and the operating unit (AU) / 'LED ind./mimic 48 LEDs' are
pre-configured in the 'Operation tree'.
6.4 Create element
You can create an element in the following ways:
● In the 'New element' window
● Via the context menu in the tree view
● In the table
Creating an element in the 'New element' window
w A ↑ 'Station' has been created.
w An element is selected for which a sub-element can also be displayed.
w The ↑ 'Site' element is not selected.
