5.4 Help and tooltips
There are two sources of information in Cerberus-Engineering-Tool:
● Help
● Tooltips
Help
There are three ways of calling up the Help function:
● Press <F1>.
● Select 'Help' > 'Help' from the menu bar.
● Click on the symbol in the toolbar.
A PDF document containing an overview of the documentation opens. To open a
document, click on its name in the overview.
Tooltips
Tooltips are windows within the software with context-sensitive detail information.
Tooltips are shown when the mouse pointer is moved over a element designation
or element property in the detail editor.
Figure 3: Example for the Tooltip of an element property
To display the Tooltip of an element, proceed as follows:
1. Highlight an element in the tree view.
a The element and its properties are displayed in the detail editor.
2. In the detail editor, move the mouse pointer over the element designation in the
uppermost tab.
a The Tooltip is displayed.
Figure 4: Example for the Tooltip of an element
