Program operation
Assigning elements
6
77 |
412
Building Technologies
A6V10210424_j_en_
--
Fire Safety
2018
-
08
-
29
6 Tree view of the assignable elements:
● Light gray text: The path leads to an element that cannot be assigned
● Bold text: The path leads to an element that can be assigned
● Bold characters, greyed out: assignable element
● Inverted characters, blue: highlighted element
7
'Always jump to next assignable element' checkbox: If the checkbox is
checked, the next assignable element is highlighted after assigning.
8
'Next assignable element (ALT+S)' button: Navigate to the next assignable
element
9
'Previous assignable element (ALT+W)' button: Navigate to the previous
assignable element
Assigning elements
1. In the task card tree view, highlight the element you would like to assign.
2. Open the 'Assign dialog' window.
3. Select the category from the list (1).
4. Select the task card in the drop-down list field (2).
5. Search for the element you want using the ID no. (4) or in the tree view (5).
6. Highlight the element.
7. Click on 'Assign'.
a The elements are assigned.
Instead of using the '
Assign
' button, you can use the keyboard shortcut <Alt> +
<A>. If necessary, several elements can be assigned in this manner without
having to change between the tree view and the 'Assign dialog' dialog with the
mouse. To do this, the 'Always jump to next assignable element' checkbox must
be activated.
By default, the first assignable element is found and displayed automatically in the
tree view (5). You can change this behavior in the pre-settings. You will find more
information on this in chapter 'General [➙ 37]'.
See also
2 General [➙ 37]
