7.8 Logger Control
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
Operating Instructions, 01/2013, A5E02951520-AC
125
Display Logger
This menu cell allows you to send the Logger contents to the display screen. This command
is effective only after a successful install. You can set the report to scroll on the screen with
or without line-wrap. Selecting line wrap, forces a line feed after approximately 40
characters. In addition, you have to enable datalogging and then select items in the Logger
Setup menu. Note that this command transmits the data from both channels/paths.
To send Logger contents to the display screen:
1. Press <Right Arrow> to access the [Display Logger] option list.
/RJJHU&RQWURO
6LHPHQV 'XDO3DWK>@3DWK
$FWLYDWHRQVFUHHQORJJHUGLVSOD\
'LVSOD\/RJJHU 2II
2XWSXW/RJJHU
/LQH:UDS
&LUFXODU0HPRU\ 1R/LQH:UDS
(VW/RJ7LPH/HIW
&OHDU/RJJHU 1R
2. Scroll cursor to either [Line Wrap] or [No Line Wrap] by pressing <Up/Down Arrow>.
3. To view Logger contents press <ENTER>.
4. To return to [Logger Control] press <MENU>.
Output Logger
This menu cell allows you to send the Logger contents to an external device (usually a
computer or printer) via the flow meter’s RS-232 Serial I/O port. This command is effective
only after a successful install. In addition, you have to enable datalogging and select data
items in the [Logger Setup] menu.
The flow meter interfaces with most serial printers or personal computers for Logger
printouts. You must use the proper cabling between the flow meter and the external device.
In addition, you must configure the RS-232 Setup correctly. You should turn off the Logger
function before you transmit an extensive printout. This will avoid contaminating the printout
with new Logger data. Logger reports are sequential ASCII text files.
To send Logger contents to the RS-232 Serial Port:
1. Check the flow meter-to-external device connections and your RS-232 Setup parameters
(see RS-232 Setup menu).
2. To access the [Output Logger] option list press <Right Arrow>.
3. Scroll the cursor to [Yes] by pressing <Up/Down Arrow>.
