Appendix
A.5 Setup Procedure for Wet-Flow Calibration
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
216 Operating Instructions, 01/2013, A5E02951520-AC
The table may contain up to 32 pairs of these slope correction factors. Note that the Kc
factor, unlike these slope correction factors, is entered as a signed percent change in rate,
while these factors are simply rate multipliers. As points are entered, the point editor will
provide list access to the already entered points plus access to the [New Point] menu cell,
used to add a new point. The table may be created in its entirety and then activated by
selecting [Yes] in the [Table Active] menu cell. The entire table may be cleared by selecting
[Yes] in the [Clear Table] menu cell.
Note
Careless use of the calibration tables can have a detrimental impact on the measurement
performance of the flow meter.
Note
Take precautions before enabling these calibration tables. Although it is unlikely that all three
tables would ever be employed in a real installation, three tables are offered for maximum
user flexibility. Since the tables can be disabled without being destroyed, 2 or 3 optimization
strategies may be tested by this means in order to determine which approach is most
effective.
A.5 Setup Procedure for Wet-Flow Calibration
Calibrated SITRANS F 1010 Portable and NEMA Flow Meter Systems
NOTICE
Data Corruption
DO NOT use the field manual installation procedure to start up a wet-flow calibrated
system. Doing so could void the calibration by corrupting essential data.
These are the only authorized instructions to be used when commissioning a wet-flow
calibrated 1010 system.
When a SITRANS F 1010 system is wet-flow calibrated, the flow display computer stores the
installation parameters in its storage memory. Each flow calibration is assigned a unique site
name. Usually, the site name corresponds to the pipe size. For example, a 3-inch carbon
steel, schedule 40 pipe would be given the name "3CS40."
