Siemens FUS1010 User Manual

Connecting
5.5 Sensor Installation
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
58 Operating Instructions, 01/2013, A5E02951520-AC
Note
Che
ck to make sure that the sensors are a matched set with the same serial numbers and
marked with an "A" and "B" (e.g., 19256A and 19256B).
Note
Sensor Model names for Version 3 op systems are as follows: 1011H Hi Precision, 1011
Universal and 991 Universal
Typical Sensor Labels


%
(%
6LHPHQV,QGXVWU\,QF
0DGHLQ86$
336%
$
16
UHY

;;;;8QLYHUVDO
① Universal Sensor model number
② Sensor size
Figure 5-10 Universal Sensor Label
